Description
Sinopec ATF HD Automatic Transmission Fluid is a multifunctional fluid formulated with high viscosity index base oils and selected additives. It is suitable for use in multi-vehicle automatic transmissions, especially meeting heavy-duty vehicle requirements.
Applications
Sinopec ATF HD Automatic Transmission Fluid is suitable for use in:
Features and benefits
-
Superior anti-shudder performance ensures smooth transmission, making the vehicle more comfortable for the driver and passengers.
-
Excellent thermal and oxidation stability minimises the formation of deposits that could lead to component wear and also ensures longer oil life.
-
Excellent protection against rust and corrosion effectively extends the service life of the automatic transmission.
-
Good compatibility with most common seals and elastomer materials used in automatic transmissions prolongs seal life and reduces leakage.
Specifications
Typical Data
| Sinopec ATF HD Automatic Transmission Fluid |
| Property |
Typical Data |
Test Method |
| Color |
Red |
ASTM D1500 |
| Kinetic viscosity (100°C), mm²/s |
7.29 |
ASTM D 445 |
| Low temperature viscosity (−20°C), mPa.s |
1000 |
ASTM D 2983 |
| Low temperature viscosity (−40°C), mPa.s |
12100 |
ASTM D 2983 |
| Flash point (COC), °C |
227 |
ASTM D 92 |
These data are given as an indication of typical values and not as exact specifications.
Industry and OEM Specifications
| Sinopec ATF HD Automatic Transmission Fluid has been formally approved |
| ZF |
TE-ML 04D, TE-ML 14B, TE-ML 16L, TE-ML 16R, TE-ML 20B |
| Volvo |
97341 |
| Voith |
H556336.XX (extended drain) (ongoing) |
| MAN |
339 Type L-1, V2, Z-2, Z-11 (ongoing) |
| MB |
236.6 (ongoing) |
| JASO (self-certified) |
JASO M315 1A |
| Meets the performance requirements of the following commercial vehicle specifications: |
| Allison |
C-4, TES-389, TES-295 |
| MAN |
339 Type L-1, V1, Z1, V2, Z-2, Z-11 |
| MB |
MB 236.1, 236.2, 236.3, 236.6, 236.7, 236.9, 236.11, 236.81, 236.91 |
| Voith |
H556335.XX, H556336.XX |
| Volvo |
97340, 97341 |
| ZF |
TE-ML 03D, TE-ML 04D, TE-ML 05L, TE-ML 14B, TE-ML 16L, TE-ML 16R, TE-ML 17C, TE-ML 20B |
| Meets the performance requirements of the following passenger vehicle specifications: |
| GM |
DEXRON® VI, DEXRON®, DEXRON® II, IID, IIE, III, III F/G/H |
| Allison |
C-3, C-4, TES 295, TES 389 |
| American Motors |
ATF +3 (SM7176-E, ATF+4 (MS9602) |
| Audi |
5 HP LT 71141 (ZF 5 HP 18 FL, 19FL, 24A), 5 HP LT 71141 (G-052-162-A1, A2) |
| BMW |
ETL-7045, 7045E (83 22 0 026 922), 7045E (3 series) |
| Caterpillar |
Power Shift TO-2 |
| Ford/Mazda |
V (XT-9-QMM5, FNR 5) |
| Ford |
MERCON® (XT-2-QDR, XT-2-QSM SYN), ESR-M2C-163-A2 |
| Honda |
Z-1 |
| Hyundai |
NWS-9638, SP-II, SP-III, SP-IV, Apollo Red 1K, JWS 3314 |
| Isuzu |
Besco ATF II, ATF III, Genuine ATF |
| Jaguar |
ATF 3403 M115, LT 71141, JLM 20238, 8342 |
| Jeep |
ATF+3, ATF+4 |
| Kia |
ATF Red 1, SP-II, SP-III, SP-IV, Apollo Red 1K |
| Mitsubishi |
Diamond SP-II, SP-III, SP-IV, J2, J3, Dia, ATF PA |
| Opel |
(All vehicles) |
| Toyota |
WS |
| Volvo |
97340, 97341, T IV (JWS 3309), 4-6 speed |
| VW |
5 HP (ZF 5 HP 30) |
| ZF |
TE-ML 11A and 11B |
