🏭 Why Lubrication Is Essential in Injection Molding
Injection molding is a cornerstone process in plastic manufacturing, used across industries like medical devices, electronics, and automotive. These machines run under high pressure, heat, and repetitive motion , making reliable lubrication a non-negotiable part of smooth operations.
Improper lubrication leads to increased wear, overheating, production delays, and expensive repairs.
🔧 Which Parts of Injection Molding Machines Need Lubrication?
-
Hydraulic Systems
The hydraulic system powers the clamping, injection, and ejection processes. It must be protected with a high-quality anti-wear hydraulic oil that can withstand high pressures and maintain stability over long operating hours. -
Heated Oil Circulation Units
Many molding machines use oil-based temperature control systems. Heat transfer oil is crucial here to keep molds at optimal temperatures without breakdown or fluid degradation. -
Slideways and Moving Components
If your machine uses guide rails or slides for mold movement, low-friction oils help reduce wear and ensure consistent motion during each cycle.
✅ Recommended Types of Lubricants for Injection Molding Machines
🛢 Anti-Wear Hydraulic Oil (ISO VG 46 or VG 68)
Ideal for powering hydraulic actuators and clamping units. Look for oils with:
-
High thermal and oxidation stability.
-
Strong anti-wear additives.
-
Rust and corrosion protection.
Best used in:
-
Hydraulic injection units.
-
Clamping systems.
-
Machines operating continuously.
🌡 Heat Transfer Oil (High Temp, Non-Conductive)
Used in closed-loop systems for mold heating and cooling. The right heat transfer oil should:
-
Operate effectively up to 290°C (554°F)
-
Resist oxidation and sludge buildup.
-
Deliver thermal stability under constant use.
Best used in:
-
Mold temperature control units.
-
Thermal fluid heaters in molding systems.
⚙️ Extreme Pressure Gear Oil (AGMA 4 or 5)
Some auxiliary systems may use gearboxes or mechanical drives. EP gear oils provide:
-
Load-carrying performance.
-
Shock-load protection.
-
Resistance to pitting and scoring.
Best used in:
-
Extruder drives.
-
Mold movement gears.
-
Chain drives or lifting systems.
🧰 Pro Tip: Build a Maintenance Schedule
Even the best oil won’t help if it’s applied late or inconsistently. Set a maintenance routine to check:
-
Oil levels weekly.
-
Filter cleanliness monthly.
-
Fluid quality quarterly (or as needed).
This extends equipment life, improves mold quality, and reduces emergency downtime.
Injection molding machines are a major investment, and keeping them lubricated with the right fluids protects your output, your tools, and your bottom line.
Whether you're running 24/7 production or a smaller-scale operation, choosing the right hydraulic oil, heat transfer oil, and gear oil is critical to staying efficient, safe, and cost-effective.
